Informācija par preci

Camera Image Sensor 1/2.8" CMOS Pixel 8 MP Max. Resolution 3840 (H) x 2160 (V) ROM 4 GB RAM 1 GB Electronic Shutter Speed 1 s–1/30,000 s Scanning System Progressive Min. Illumination 0.005 lux@F1.6 (Color, 30 IRE); 0.0005 lux@F1.6 (B/W, 30 IRE); 0 lux (illuminator on) Illumination Distance 100 m (328.08 ft) (IR); 50 m (164.04 ft) (White light) Illuminator On/Off Control Zoom Prio; Manual; Auto; Off Illuminator Number 2 (IR); 2 (Dual light fusion) Lens Focal Length 5 mm–125 mm Max. Aperture F1.6-F3.6 Field of View H: 53.1°-3.4°; V: 30.4°-1.9°; D: 59.3°-3.9° Optical Zoom 25 x Focus Control Auto; semi-auto; manual Close Focus Distance 0.1m-1.5 m (0.33 ft–4.92 ft) Iris Control Auto; manual DORI Distance Detect Observe Recognize Identify 3310 m (10859.58 ft) 1308 m (4291.34 ft) 662 m (2171.92 ft) 331 m (1085.96 ft) PTZ Pan/Tilt Range Pan: 0° to 360° endless; Tilt: –15° to +90°, auto flip 180° Manual Control Speed Pan: 0.1°/s–200°/s; Tilt: 0.1°/s–120°/s Preset Speed Pan: 0.1°/s–240°/s; Tilt: 0.1°/s–200°/s Preset 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Power-off Memory Yes Idle Motion Pattern; Preset; Scan; Tour Intelligence IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; linkage tracking Face Detection Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots Auto Tracking Yes SMD SMD 4.0 Auto Patrol It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets Active Deterrence Light Warning Red-blue light warning Flash duration: 5 s–30 s Flash frequency: high, medium, low Sound Warning Offers 11 types of sound alarms, and supports importing custom sound alarms. Video Video Compression H.264H; H.264B; Smart H.265+; H.265; MJPEG (Sub Stream); Smart H.264+; H.264M Streaming Capability 3 streams Resolution 4K (3840 x 2160); 4M (2560 x 1440); 3M (2048 x 1536); 3M (2304 x 1296); 1080p (1920 x 1080); 1.3M (1280 x 960); 720p (1280 x 720); D1 (704 x 576/704 x 480); VGA (640 x 480); CIF (352 x 288/352 x 240) Video Frame Rate Main stream: 4K/4M/3M/1080p/1.3 M/720p@(1–25/30 fps) Sub stream 1: D1/CIF/VGA@(1–25/30 fps) Sub stream 2: 1080p/1.3 MP/720p@(1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H264: 128 Kbps–16,384 Kbps H265: 128 Kbps–11,776 Kbps Day/Night Auto (ICR); Color/B/W BLC Yes WDR DWDR HLC Yes White Balance Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp Gain Control Auto; manual Noise Reduction 2D NR; 3D NR Motion Detection Yes Region of Interest (RoI) Yes Image Stabilization Electronic (EIS) Defog Electronic Digital Zoom 16x Image Rotation 180° Privacy Masking Up to 24 areas can be set, with up to 8 areas in the same view; Multiple colors available S/N Ratio ? 55 dB Audio Audio Compression PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 Network Network Port RJ-45 (10/100 Base-T) Network Protocol FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP Interoperability ONVIF (Profile S & Profile G & Profile T); CGI; SDK; P2P Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage Micro SD card (512 GB); FTP/SFTP; NAS Browser IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; Safari 10 and later versions Management Software DMSS; DSS Pro Mobile Client iOS; Android Certification Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 Port Audio Input 1 channel (LINE IN, bare wire) Audio Output 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) Alarm Input 2 (on-off value input: 0–5 VDC) Alarm Output 1 channel Alarm Linkage Capture; recording; send email; preset; tour; pattern; alarm digital output; audio; warning light Alarm Event Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection Power Power Supply 12 VDC, 3 A ± 10%; PoE+ (802.3at) Power Consumption 12 VDC: Basic: 8 W; Max: 16 W (white light + heated glass + PTZ on + alarm + red and blue light flashing) POE: Basic: 9 W; Max: 17 W (white light + heated glass + PTZ on + alarm + red and blue light flashing) Environment Operating Temperature –40 °C to +65 °C (–40 °F to +149 °F) Operating Humidity ? 95% Protection TVS 6000 V lightning proof; IP66; surge protection; voltage transient protection Structure Product Dimensions 269.9 mm x D 160.0 mm (10.63" x D 6.30") Net Weight 2.6 kg (5.73 lb) Gross Weight 4 kg (8.82 lb)
