Camera Image Sensor 1/2.8" CMOS Pixel 2 MP Max. Resolution 1920 (H) Ч 1080 (V) ROM 128 MB RAM 256 MB Electronic Shutter Speed 1/1 s–1/30,000 s Scanning System Progressive Min. Illumination Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR light on) Illumination Distance 100 m (328.08 ft) (IR) Illuminator On/Off Control Zoom Prio; Manual; Smart IR Illuminator Number 3 (IR) Lens Focal Length 4.8 mm–120 mm Max. Aperture F1.6–F3.5 Field of View H: 58.5°–2.8°; V: 33.2°–1.5°; D: 67.5°–3.2 Optical Zoom 25x Focus Control Auto; semi-auto; manual Close Focus Distance 0.1 m–1.5 m (0.33 ft–4.92 ft) Iris Control Auto DORI Distance Detect Observe Recognize Identify 1,613 m (5,291.99 ft) 646 m (2,119.42 ft) 323 m (1,059.71 ft) 161 m (528.22 ft) PTZ Pan/Tilt Range Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° Manual Control Speed Pan: 0.1°/s–80°/s Tilt: 0.1°/s–80°/s Preset Speed Pan: 80°/s; Tilt: 80°/s Preset 300 Tour 8 (up to 32 presets per tour) Pattern 5 Scan 5 Power-off Memory Yes Idle Motion Preset;Pattern;Tour;Scan PTZ Protocol DH-SD Pelco-P/D (Auto recognition) Intelligence IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification Face Detection Supports face detection, capturing pictures, and face enhancement SMD Yes Video Video Compression Smart H.265+;H.265;Smart H.264+;H.264;H.264B;MJPEG(Sub Stream) Streaming Capability 3 streams Resolution 1080p (1920 Ч 1080); 960p (1280 Ч 960); 720p (1280 Ч 720); D1 (704 Ч 576/704 Ч 480); VGA (640 Ч 480); CIF (352 Ч 288/352 Ч 240) Video Frame Rate Main stream: 1080p/960p/720p@(1–25/30 fps) Sub stream 1: D1/VGA/CIF@(1–25/30 fps) Sub stream 2: 1080p/960p/720p@(1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H.264: 1792 kbps–8192 kbps H.265: 512 kbps–5632 kbps Day/Night Auto (ICR)/Color/B/W BLC Yes WDR 120db HLC Yes White Balance Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp Gain Control Auto; manual Noise Reduction 2D NR; 3D NR Motion Detection Yes Region of Interest (RoI) Yes Image Stabilization Electronic (EIS) Defog Electronic Digital Zoom 16Ч Image Rotation 180° Privacy Masking Up to 24 areas can be set, with up to 8 areas in the same view S/N Ratio ? 55 dB Audio Audio Compression G.711a; G.711Mu; G.722.1; G.726; MPEG2-Layer2; G.729 Network Network Port RJ-45 (10/100 Base-T) Network Protocol HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;Qos;FTP;UPnP;ICMP;SNMP;SNMPv1/v2c/v3(MIB-2);IGMP;ARP;RTCP;RTP;PPPoE;IP Filter;RTMP;Bonjour;TCP;SMB;NFS Interoperability CGI; Dahua SDK; API; SDK; ONVIF (Profle S&G&T) Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage FTP; Micro SD card (512 GB); NAS Browser IE 7 and later versions Chrome Firefox Safari Management Software Smart PSS;DSS;DMSS;IVSS;ConfigTool;NVR Mobile Client iOS;Android;iPhone;iPad Certification Certifications CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4- 2014 Port Audio Input 1 channel (LINE IN, bare wire) Audio Output 1 channel (LINE OUT,bare wire) Alarm Linkage Capture; preset; tour; pattern; recording; alarm digital input; audio; send email Alarm Event Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection Alarm I/O 2/1 Audio I/O 1/1 Power Power Supply 12 VDC/3 A (± 10%) PoE (802.3at) Power Consumption Basic: 12 W Max.: 20 W (IR light) Environment Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F) Operating Humidity ?95% Protection IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 270.4 mm Ч ?160.0 mm (10.65" Ч ?6.30") Net Weight 2.4 kg (5.29 lb) Gross Weight 3.9 kg (8.60 lb)
