Informācija par preci

Features:  • H.265/H.264/MJPEG/MPEG4 codec decoding • Max 320Mbps incoming bandwidth • Up to 12Mp resolution preview&playback • 2HDMI/VGA simultaneous video output • 3D intelligent positioning with Dahua PTZ camera   Technical Specifications:  System • Main Processor Quad-core embedded processor • Operating System Embedded LINUX Display • Interface 2 HDMI (1 HDMI up to 3840x2160, Different Source ), 1 VGA • Resolution 3840x2160, 1920×1080, 1280×1024, 1280×720, 1024×768 Multi-screen Display • 1st screen: 16CH: 1/4/8/9/16 2nd screen: 1/4/8/9/16 • OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording Video Detection and Alarm • Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips • Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering • Alarm input 16 Channel, Low Level Effective, Green Terminal Interface • Relay Output 6 Channel, NO/NC Programmable, Green Terminal Interface • Tracking Trigger Event N/A Playback and Backup • Sync Playback 1/4/9/16 • Search Mode Time /Date, Alarm, MD and Exact Search (accurate tosecond) Playback Function • Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom • Backup Mode USB Device/Network/Internal SATA burner/eSATA Device Storage • Internal HDD 8 SATA III Ports, up to 8TB capacity for each HDD • eSATA 1 eSATA port • SAS N/A Auxiliary Interface • Front Cover N/A • USB 4 ports (2 Rear USB3.0,2 Front USB2.0) • RS232 1 Port, for PC Communication and Keyboard • RS485 1 Port, for PTZ Control Third-party Support • Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more Audio and Video • IP Camera Input 16 Channel • Two-way Talk 1 Channel Input, 1 Channel Output, RCA Recording • Compression H.265/H.264/MJPEG/MPEG4 • Resolution 12Mp/8Mp/6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc. • Record Rate 320Mbps • Bit Rate 16kbps~20Mbps for per channel • Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop • Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec Network • Interface 1 RJ-45 port (10/100/1000Mbps) • Ethernet Port 1 Independent 1000Mbps Ethernet Port • PoE 16 ports (IEEE802.3af/at) Network Function • HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P • Optical Fiber Interface N/A • Max. User Access 128 users • Smart Phone iPhone, iPad, Android • Interoperability ONVIF 2.4, CGI Conformant Electrical • Power Supply Single, AC 100~240V, 50/60 Hz • Power Consumption
