Informācija par preci

Miniature circuit breaker (MCB), Acti9 iC60N, 1P, 2A, C curve, 6000A (IEC/EN 60898-1), 50kA (IEC/EN 60947-2)device applicationDistributionDiapazonsActi9Produkta nosaukumsActi9 iC60Produkta vai sastāvdaļas veidsMiniature circuit-breakerIerīces īsais nosaukumsIC60NPolu apraksts1PNumber of protected poles1[In] rated current2 ATīkla veidsDCACTrip unit technologyThermal-magneticcurve codeCBreaking capacity6000 A Icn 230 V AC 50/60 Hz EN/IEC 60898-150 kA Icu 12...60 V AC 50/60 Hz EN/IEC 60947-250 kA Icu 220...240 V AC 50/60 Hz EN/IEC 60947-250 kA Icu 100...133 V AC 50/60 Hz EN/IEC 60947-210 kA Icu 60...72 V DC EN/IEC 60947-215 kA Icu 12...60 V DC EN/IEC 60947-2Utilisation categoryCategory A EN 60947-2Category A IEC 60947-2Suitability for isolationYes EN 60898-1Yes EN 60947-2Yes IEC 60898-1Yes IEC 60947-2StandartiEN 60898-1IEC 60898-1EN 60947-2IEC 60947-2Quality labelsNFPapildinošsTīkla frekvence50/60 HzMagnetic tripping limit8 x In +/- 20 %[Ics] rated service breaking capacity50 kA 100 % EN 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % IEC 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % IEC 60947-2 - 100...133 V AC 50/60 Hz50 kA 100 % EN 60947-2 - 100...133 V AC 50/60 Hz6000 A 100 % EN 60898-1 - 230 V AC 50/60 Hz6000 A 100 % IEC 60898-1 - 230 V AC 50/60 Hz10 kA 100 % EN 60947-2 - 72 V DC10 kA 100 % IEC 60947-2 - 72 V DC15 kA 100 % EN 60947-2 - 12...60 V DC15 kA 100 % IEC 60947-2 - 12...60 V DCLimitation class3 EN 60898-13 IEC 60898-1[Ui] rated insulation voltage500 V AC 50/60 Hz EN 60947-2500 V AC 50/60 Hz IEC 60947-2[Uimp] rated impulse withstand voltage6 kVEN 60947-26 kVIEC 60947-2Contact position indicatorYesKontroles veidsToggleVietējā signalizācijaTrip indicatorMontāžas režīmsFixedMontāžas atbalstsDIN railComb busbar and distribution block compatibilityTop or bottom YES9 mm pitches2Augstums85 mmPlatums18 mmDziļums78,5 mmNeto svars0,215 kgKrāsaBaltsMechanical durability20000 cikliElectrical durability10000 cikliConnections - terminalsSingle terminal top or bottom) 1…25 mm² rigidSingle terminal top or bottom) 1…16 mm² flexibleWire stripping length14 mm top or bottomTightening torque2 N.m top or bottomearth-leakage protectionWithoutVideIP degree of protectionIP20 IEC 60529IP20 EN 60529pollution degree3 EN 60947-23 IEC 60947-2Pārsprieguma kategorijaIVTropicalisation2 IEC 60068-1Relative humidity95 % 55 °CDarbības augstums0...2000 mambient air temperature for operation-35…70 °CApkārtējā gaisa temperatūra uzglabāšanai-40…85 °C
