Informācija par preci

Features:&#x4;&#x4;• 305m /carton outdoor UTP CAT5e, power over Ethernet, compatible with one cable.&#x4;• High-purity (99.97%) Oxygen-Free Copper conductor material.&#x4;• Customized MDPE outer sheath; meet ANSI/TIA 568-C.2 flame retardant class certified.&#x4;• Environmentally friendly PVC and all materials used are RoHS compliant.&#x4;&#x4;Technical Specifications:&#x4;&#x4;• Material OFC (oxygen free copper) (99.97% purity).&#x4;• Conductor diameter: 0.50 mm ± 0.01 mm.&#x4;• American wire Gauge: 24AWG.&#x4;• Insulation material: HDPE.&#x4;• Insulation min. average thickness: 0.21mm.&#x4;• Insulation diameter: 0.89mm±0.06mm.&#x4;• Color: 8-core, blue, white/blue; orange, white/orange; green, white/green; brown, white/brown.&#x4;• Sheath material: MDPE.&#x4;• Sheath min. average thickness 0.7mm.&#x4;• Sheath Diameter: 5.2 mm ± 0.4 mm.&#x4;• Max. DC resistance of single conductor 9.5 Ohm/100m.&#x4;• Min. insulation resistance 5000MOhm·km.&#x4;• Max. DC resistance unbalance: 2% (pair intra), 4% (pairs inter).&#x4;• Dielectric strength: No breakdown with 1KV DC for 1 min.&#x4;• Max. attenuation: 22dB/100m@100MHz.&#x4;• Characteristic impedance: 100 ± 15Ohm.&#x4;• Near end cross talk: > /= 35.30 dB/100 m@100 MHz.&#x4;• Return loss: > /= 20.1 dB/100 m@100 MHz.&#x4;• Elongation at break: Sheath > /= 350%, Insulation > /= 300%.&#x4;• Tensile strength: Sheath > /= 12 MPa, Insulation > /= 16 MPa.&#x4;• Installation bending radius: > 8 times of outer cable diameter.&#x4;• Conductor elongation at break: > /= 15%.&#x4;• Shrinkage of insulation: < / = 5%.&#x4;• Operation temperature: –30°C to +60°C.&#x4;• Installation temperature: –5°C to +50°C.&#x4;• Storage temperature: –10°C to +40°C; Humidity:
